Residential meter 13mm R160 single jet cold water 7/8-3/4

Single-jet flow meter DN 13. The single-jet flow meter guarantees the best starting values ​​and the highest possible measurement accuracy and stability at an optimum price/performance ratio. When performing demanding measurement tasks, it delivers precise measurement results thanks to its carefully designed design down to the last detail: Hydraulically optimised housing Improved turbine support Low-friction magnetic coupling With a ratio of Q3/Q1=160 (comparable to the previous precision class C) when mounted horizontally, it meets the highest demands on reliability and measurement accuracy. At the same time, the flow meter is robust and has a wide measuring range. The flow meter is also enclosed in a robust copper sheath and is therefore optimally protected against condensation, dust or atmospheric influences. Features: Dry-dial flow meter with magnetic coupling. Maximum precision of the flow rate For cold water up to 30°C Flow rate equipped with 8 rollers as standard 355° rotating flow rate MAP 16 pressure phase Horizontal and vertical mounting position possible Feedback-free sweeping as standard Retrofittable with pulse module, M-Bus module or wireless M-Bus module MID approved. Maximum temperature 30° C. Pre-equipped for use with pulse transmitter (purchased separately). Top quality, made in Spain. Diameter 13 - 1/2. Length without fitting 11.5 cm. Flow rate 2.5 m3/h. Inlet thread 7/8 and outlet 3/4.

Product Features:

• Single jet counter DN 13.


• Q3/Q1 ratio=160 in horizontal mounting.


• Robust and with a wide measuring range.


• Dry dial watchmaking with magnetic coupling.

Frequently Asked Questions:

What is the maximum operating temperature of the meter?
The maximum operating temperature is 30º C.

What type of clock does the counter have?
The clock is a dry dial with magnetic coupling.

Is it prepared for use with a pulse emitter?
Yes, it comes pre-equipped for use (purchased separately).

What is the length without fitting of the meter?
The length without fitting is 11.5 cm.

What is the flow rate of the meter?
The flow rate is 2.5 m3/h.
