- New
Star-Plus 350mm Sand Filter for Swimming Pools with 1 1/2" Side Valve | Monobloc Filter with 5 m³/hour Capacity for Residential
€381.95
Impuestos incluidos
Star-Plus 350mm sand filter with a flow rate of 5 m³/h and a 1 1/2" side valve. The compact and durable solution to keep your pool water clean, crystal clear, and perfectly filtered all season long.
Maintaining crystal-clear, healthy pool water is essential for fully enjoying your leisure space. Introducing the Star-Plus 350mm Sand Filter with 1 1/2" Side Valve , a robust and efficient filtration solution specifically designed for residential pools seeking superior performance and exceptional durability. This monobloc system combines a heavy-duty tank with a 6-way selector valve, ensuring thorough cleaning and easy maintenance.
The Star-Plus 350mm model is designed to deliver an ideal flow rate of 5 m³/hour , making it the perfect companion for medium-sized pools. Its compact design and premium materials ensure a long lifespan, withstanding continuous exposure to chemicals and sunlight. The filter sand (not included) settles optimally within the tank, effectively capturing impurities, dirt, and fine particles, restoring unparalleled clarity to your pool.
Optimized Performance and Ease of Use
The key to this filter's effectiveness lies in its seamless integration: the 350mm tank and 1 1/2-inch side-mounted valve work in perfect harmony to manage all the necessary filtration cycles. The side-mounted selector valve greatly simplifies routine operations, allowing for easy switching between filtration, backwash, rinse, recirculation, drain, and closed functions, all from a single intuitive control.
Installation is straightforward thanks to its monobloc design, simplifying the process and ensuring a perfect seal. Investing in the Star-Plus 350mm Filter is investing in peace of mind and the quality of your pool water throughout the season.
Detailed Technical Specifications
Main Specifications:
- Product Reference: BAE57470
- Filter Diameter: 350 mm
- Nominal flow rate: 5 m³/hour (ideal for residential swimming pools)
- Valve Type: 6-Way Side Selector Valve
- Valve Connection: 1 1/2 inches
- Construction: Monobloc, optimized for maximum structural strength.
- Tank Material: High-density blow-molded polyethylene (resistant to corrosion and UV rays).
- Required Filter Medium: Siliceous sand (specific granulometry, not included).
- Valve Functions: Filter, Backwash, Rinse, Recirculate, Drain, Close.
- Maintenance: Simplified thanks to the location and design of the valve.
Frequently Asked Questions about the Star-Plus 350mm Filter
1. What type of sand is compatible with this filter?
This filter requires silica sand with a particle size typically between 0.4 and 0.8 mm. It is crucial to consult the exact specifications of the sand manufacturer to ensure optimal filtration performance and proper backwashing.
2. Do I need any additional accessories for installation?
The filter comes with the tank and selector valve. You will need to purchase separately the appropriate filter sand, the hoses for connecting to the pump and the pool's plumbing system, and possibly a pressure gauge if it is not integrated into the valve.
3. What type of pumps is this 5 m³/hour filter compatible with?
It is designed to work efficiently with pool pumps whose nominal flow rate is set to 5 m³/hour. It is important that the pump does not significantly exceed this flow rate to avoid damage to the tank or ineffective filtration.
4. How often should I perform backwashing?
Backwashing should be performed when the filter pressure increases between 0.5 and 0.8 bar above the initial resting pressure or, at a minimum, once a week during the peak season of pool use.
5. Is it resistant to common pool chemicals?
Yes, the tank is made of high-strength plastic materials designed to withstand chlorine, algaecides, and pH regulators commonly used in pool water treatment.
BAE57470
20 Items
Data sheet
No customer reviews for the moment.
