Very resistant 3/4 "and 1/2" impact sprinkler designed for small and medium residential and public automatic irrigation installations. These sprinklers are designed to work at low pressure and flow with high performance in recycled water.
Performance characteristics
• Range: 6.7 to 13.7 meters.
• Pressure: 1.7 to 4.1 bar.
• Flow: 0.34 to 1.91 m3 / h.
• Double female threaded bottom socket: 1/2 ”(15/21) and 3/4” (20/27).
• Female side socket: 1/2 ”(15/21).
Heavy duty 3/4" and 1/2" impact sprinkler for small and medium-sized residential and public automatic irrigation systems. These sprinklers are designed to work at low pressure and flow with high performance in recycled water.
• Reliable impact mechanism.
• 7.6 cm pop-up height.
• Interchangeable, colour-coded bayonet-type nozzles.
• 5 nozzles with flow rate proportional to the irrigated surface + 2 low-angle nozzles (Upon request, it takes 10 days).
• Nozzle change without tools.
• Double-counterbalanced impact arm: slow rotation with excellent reach.
• Low pressure and flow operation.
• Only one model for full circle or sectorial.
• Anti-splash «PJ™» arm.
• Jet adjustment screw.
• Multifunctional cleaning seal.
• Reversing lever that allows sectorial irrigation.
Operating characteristics
• Range: 6.7 to 13.7 meters.
• Pressure: 1.7 to 4.1 bars.
• Flow rate: 0.34 to 1.91 m3/h.
• Double female thread bottom inlet: 1/2” (15/21) and 3/4” (20/27).
• Female side inlet: 1/2” (15/21).
