Maximize the performance and safety of your photovoltaic installation with the 6 mm² Red Solar Cable in a 100-meter roll . Designed specifically for connecting solar panels and renewable energy system components, this conductor meets the highest technical standards on the market. Its H1Z2Z2-K certification guarantees exceptional durability in both residential and industrial installations, withstanding extreme weather conditions without degradation.

Maximum efficiency and safety for your photovoltaic installation

The core of this cable is made of high-purity tinned electrolytic copper, optimized to provide excellent electrical conductivity and minimize energy loss over long distances. Its advanced cross-linked elastomer insulation offers superior resistance to UV rays, ozone, abrasion, and extreme temperatures, allowing continuous operation in ranges from -40°C to +90°C.

Furthermore, this solar cable features low smoke zero halogen (LSZH) properties, significantly increasing safety in the event of a fire by preventing the release of toxic and corrosive gases. Its superior flexibility facilitates quick and clean installation in confined spaces and complex conduits.

Features of the Solar Cable 6 mm² Red 100 m

• Product reference: B25038613


• Conductor cross-section: 6 mm²


• Exterior color: Red (ideal for positive polarity)


• Roll length: 100 meters


• Cable standard: H1Z2Z2-K


• Insulation type: Halogen-free cross-linked elastomer


• Conductor: Class 5 tinned electrolytic copper


• Thermal resistance: Withstands up to 120 °C on the conductor (for 20,000 hours)


• Estimated durability: Over 25 years under optimal outdoor conditions

Frequently Asked Questions about the H1Z2Z2-K Solar Cable

Why is it important to use H1Z2Z2-K cable in solar installations?

The H1Z2Z2-K standard is currently the only one approved for photovoltaic installations according to European regulations. It guarantees that the cable can withstand direct current (DC), high voltages, direct solar radiation, and aggressive atmospheric agents without losing its insulating properties.

Can I use this red cable for alternating current or negative current?

Although technically it is an electrical conductor and would work, due to regulations and good installation practices, the red wire is reserved exclusively to identify the positive (+) polarity in direct current, facilitating maintenance and avoiding connection errors.

Is it suitable for underground or piped installations?

Yes, this cable has high resistance to moisture and chemical agents, so it can be installed outdoors or under protective tubing, in cable trays or buried directly if the appropriate tubular protections are used.
