- Nuevo
KIT Automatic Irrigation 6 zones for electric irrigation. Timer set + Solenoid valves + Installation accessories
€261.89
Impuestos incluidos
10 1/2 "sprinklers with a range of 4.6 to 10.7 m and an adjustable angle of irrigation.
Intended for small and medium-sized residential and public automatic irrigation installations. These sprinklers are designed to work at low pressure and flow with high performance in recycled water.
characteristics
- Alcance: 4,6-10,7 m.
- Minimum reach using reach reduction screw: 2.9 m.
- Pressure: 1.7-3.8 bars.
- Caudal: 0,12-1,04m3/h.
- 1/2 ”(15/21) female threaded socket.
- Sector adjustment: 40 ° -360 °.
Dimensions
Lifting height: 10.2 cm.
Body height: 16.8 cm.
Exposed diameter: 2.9 cm.
Automatic Irrigation Kit
Automatic Irrigation Kit 6 irrigation zones for 32mm connection. The automatic irrigation system allows us to automate the irrigation of your garden in an easy and simple way. Automatic irrigation set containing:
Product Features:
- Number of stations: .
- Wardrobe: Interior.
- Independent programs: 2.
- Start times per program: 4.
Frequently Asked Questions:
What are the dimensions of the Solenoid Valve?
Height: 11.7 cm. Length: 11.2 cm. Width: 7.9 cm.
What does the automatic irrigation kit include?
- Electric programmer with 6 irrigation zones.
- 4 Rain Bird 100HV 24v 1 solenoid valves .
- Irrigation box.
- 3 collector crosses.
- Mounting accessories.
Is the programmer compatible with rain sensors from other brands?
Yes, it is compatible with rain sensors from any brand.
What is the pressure and flow rate of the solenoid valve?
Pressure: 1.0 to 10.3 bar. Flow rate: 0.05 to 6.82 m3/h.
What is the resistance of the solenoid valve coil?
Coil resistance: 52 to 55 Ohms.
What warranty does the Irrigation Programmer have?
The Irrigation Programmer has automatic protection against short circuits and does not lose memory in the event of a power outage.
Pack1ELC6-HV6
154 Artículos
Ficha técnica
- Color
- Negro
Referencias específicas
No customer reviews for the moment.
