Irrigation solenoid valve

Works with electric programmers of any brand on the market.

Product Features:

• Pressure: 1.0 to 10.3 bar

• Flow rate: 0.05 to 6.82 m3/h

• Temperature: Maximum water temperature 43°C; Maximum ambient temperature 52°C

• 24V AC 50/60HZ solenoid valve

Frequently Asked Questions:

How is the solenoid valve serviced?
- Multiple connection captive screws for easy maintenance. - Quick access to the diaphragm with only four screws. - Diaphragm locating element for reliable maintenance.

What ensures the reliability of the solenoid valve?
- Polypropylene body with fiberglass for greater strength. - Normally closed reverse flow design. - Hassle-free repair with few parts. - Diaphragm with self-cleaning 200 micron pilot filter and stainless steel spring.

In which applications can the solenoid valve be used?
- Works in low flow and localized irrigation applications when the RBY filter is installed upstream. - External purge to manually clean the system and remove dirt particles during installation and start-up of the system. - Internal purge for manual use without external water loss.

What are the dimensions of the solenoid valve?
- Height: 11.7 cm - Length: 11.2 cm - Width: 7.9 cm

What is the resistance of the solenoid valve coil?
- Coil resistance: 52 to 55 Ohms
